Rinnai Hotflo 160 Litre
Medium Capacity Electric Storage
Features
* Vitreous Enamel lined steel tank for added durability
* Inbuilt anode protection extends the life of the tank
* Dual handed, allows increased flexibility during installation
* Pressure temperature relief valve included
* Suitable for internal and external use
* Thermostatically controlled with safety temperature shut off for added peace of mind
Specifications
Electrical Supply |
AC 240V 50Hz |
Tank Diameter |
515 |
Heating Elements Available (kW) |
1.8 / 2.4 / 3.6 |
Weight Empty (kg) |
66 |
Overall Height |
1530 |
Outlet Height |
1310 |
Inlet Height |
225 |
Electrical Connection Height – Lower (mm) |
155 |
Electrical Connection Height – Upper (mm) |
946 (160L tank only) |
Relief Valve Setting (kPa) |
1000 |
Expansion Control Valve Setting (kPa) |
850 |
Max inlet pressure (with ECV – kPa) |
680 |
Max inlet pressure (without ECV – kPa) |
800 |
Water Connections |
RP 3/4 20mm |
Ingress Protection Rating (AS1939) |
IPX4 |
Rated Capacity (Litres) |
160 |
